USB nomenclature
Link
Listed since
2020-09-10
Viewing angle
178°/178°
manufacturer
Eizo
VESA
100x100 (occupied)
Shape
straight (flat)
Colour depth
8bit (16.7 Mio. colours)
Panel
IPS
Weight
8.50kg (with pedestal), 5.70kg (without pedestal)
Brightness
350cd/m² (typical)
Response time
5ms (GtG)
Power supply
internal
Backlight
LED, blue light filter, flicker-free
Function
monitor (stationary)
Coating
non-glare (matte)
Contrast
1.000:1 (static)
Speakers
loudspeaker (2x 1W)
Refresh rate
60Hz (2560x1440)
Special features
security lock (Kensington Security Slot), light sensor, KVM switch, slim bezel, HDCP 2.2
Power consumption
164W (maximum), 16W (typical), 0.5W (standby), 16W (Energy label old A+++ to G)
Dimensions
611x369x230mm (WxHxD) with pedestal compressed, 611x546x230mm (WxHxD) with pedestal extracted, 611x357x56mm (WxHxD) without pedestal
Ergonomics
with pedestal, height-adjustable (177mm), Pivot (±90°), rotatable (±172°), tiltable (+35°/-5°)
Signal frequency
31-76kHz (H) / 59-61Hz (V)
Warranty
five years (on site-replacement-Service)
Screen-to-Body-Ratio
92.13% (calculated)
Colour
black (Display surrounding) / white (lower bezel) / white (pedestal) / white (back side)
Resolution
2560x1440 (WQHD), 16:9, 109ppi
Screen size
27" (68.6cm), Class: 26"-27"
Connectors
1x HDMI 1.4, 1x DisplayPort 1.2, 1x USB-C 3.0 with DisplayPort 1.2 (Upstream, 5Gb/s, PD 70W), 1x USB-C 3.0 with DisplayPort 1.2 (downstream, 5Gb/s, PD 15W), 1x USB-B 3.0 (Upstream, 5Gb/s), 3x USB-A 3.0 (downstream, 5Gb/s), 1x 3.5mm jack (Line-Out), 1x RJ-45 1Gb LAN, 1x AC-In C14 (mains connection)
Shape
straight (flat)
Response time
5ms (GtG)
Colour depth
8bit (16.7 Mio. colours)
Backlight
LED, blue light filter, flicker-free
Contrast
1.000:1 (static)
Brightness
350cd/m² (typical)
Warranty
five years (on site-replacement-Service)
Colour
black (Display surrounding) / white (lower bezel) / white (pedestal) / white (back side)
Ergonomics
with pedestal, height-adjustable (177mm), Pivot (±90°), rotatable (±172°), tiltable (+35°/-5°)
Bandwidth
angenäherter bandwidth-demand: 5.31Gb/sHDMI 1.4 max. Bandwidth: 8.16Gb/sDisplayPort 1.2 max. Bandwidth: 21.6Gb/sUSB-C 3.0 with DisplayPort 1.2 max. Bandwidth: 21.6Gb/sUSB-C 3.0 with DisplayPort 1.2 max. Bandwidth: 21.6Gb/s
Power consumption
164W (maximum), 16W (typical), 0.5W (standby), 16W (Energy label old A+++ to G)
Special features
security lock (Kensington Security Slot), light sensor, KVM switch, slim bezel, HDCP 2.2
