USB nomenclature
Link
Listed since
2020-09-10
Viewing angle
178°/178°
manufacturer
Eizo
VESA
100x100 (occupied)
Shape
straight (flat)
Colour depth
8bit (16.7 Mio. colours)
Panel
IPS
Brightness
350cd/m² (typical)
Weight
7.60kg (with pedestal), 4.90kg (without pedestal)
Response time
5ms (GtG)
Power supply
internal
Backlight
LED, blue light filter, flicker-free
Function
monitor (stationary)
Coating
non-glare (matte)
Contrast
1.000:1 (static)
Speakers
loudspeaker (2x 1W)
Signal frequency
31-76kHz (H) / 59-61Hz (V)
Warranty
five years (on site-replacement-Service)
Colour
black (Display surrounding) / white (lower bezel) / white (pedestal) / white (back side)
Refresh rate
60Hz (1920x1200)
Resolution
1920x1200 (WUXGA), 16:10, 94ppi
Special features
security lock (Kensington Security Slot), presence sensor, light sensor, KVM switch, slim bezel
Dimensions
531x356x230mm (WxHxD) with pedestal compressed, 531x538x230mm (WxHxD) with pedestal extracted, 531x344x54mm (WxHxD) without pedestal
Ergonomics
with pedestal, height-adjustable (182mm), Pivot (±90°), rotatable (±172°), tiltable (+35°/-5°)
Screen-to-Body-Ratio
92.19% (calculated)
Power consumption
156W (maximum), 11W (typical), 0.5W (standby), 12W (Energy label old A+++ to G)
Screen size
24.1" (61.2cm), Class: 23"-24"
Connectors
1x HDMI 1.4, 1x DisplayPort 1.2, 1x USB-C 3.0 with DisplayPort 1.2 (Upstream, 5Gb/s, PD 70W), 1x USB-C 3.0 with DisplayPort 1.2 (downstream, 5Gb/s, PD 15W), 1x USB-B 3.0 (Upstream, 5Gb/s), 3x USB-A 3.0 (downstream, 5Gb/s), 1x 3.5mm jack (Line-Out), 1x RJ-45 1Gb LAN, 1x AC-In C14 (mains connection)
