Listed since
2022-03-28
USB nomenclature
Link
Viewing angle
178°/178°
manufacturer
Eizo
VESA
100x100 (occupied)
Shape
straight (flat)
Colour depth
8bit (16.7 Mio. colours)
Panel
IPS
Brightness
250cd/m² (typical)
Weight
7.20kg (with pedestal), 4.50kg (without pedestal)
Response time
5ms (GtG)
Power supply
internal
Backlight
LED, blue light filter, flicker-free
Function
monitor (stationary)
Coating
non-glare (matte)
Resolution
1920x1080 (FHD), 16:9, 93ppi
Contrast
1.000:1 (static)
Refresh rate
60Hz (1920x1080)
Speakers
loudspeaker (2x 1W)
Warranty
five years (on site-replacement-Service)
Signal frequency
31-68kHz (H) / 59-61Hz (V)
Ergonomics
with pedestal, height-adjustable (191mm), Pivot (±90°), rotatable (±172°), tiltable (+35°/-5°)
Colour
black (Display surrounding) / white (lower bezel) / white (pedestal) / white (back side)
Special features
security lock (Kensington Security Slot), light sensor, KVM switch, slim bezel
Screen-to-Body-Ratio
90.62% (calculated)
Power consumption
155W (maximum), 11W (typical), 0.5W (standby)
Dimensions
537.8x332.4x230mm (WxHxD) with pedestal compressed, 537.8x523.4x230mm (WxHxD) with pedestal extracted, 537.8x320.4x57.4mm (WxHxD) without pedestal
Screen size
23.8" (60.5cm), Class: 23"-24"
Connectors
1x HDMI 1.4, 1x DisplayPort, 1x USB-C 3.0 with DisplayPort (Upstream, 5Gb/s, PD 70W), 1x USB-C 3.0 (downstream, 5Gb/s, PD 15W), 1x USB-B 3.0 (Upstream, 5Gb/s), 3x USB-A 3.0 (downstream, 5Gb/s), 1x 3.5mm jack (Line-Out), 1x RJ-45 1Gb LAN, 1x AC-In C14 (mains connection)
